| Indoor | Outdoor | ||||||||||
| Model | PL8 | P2 | P2.5 | P3 | P4 | Model | P4.8 | P5 | P6 | P8 | P10 |
| Pixel Pitch(mm) | 1.875 | 2 | 2.5 | 3 | 4 | Pixel Pitch(mm) | 4.8 | 5 | 6 | 8 | 10 |
| Diameter（m) | 1.5，2.5 | 1.5，1.6，2 | 1，1.2，1.5，2 | 1.2，1.5，1.6，1.8，2，2.6，3 | 1，1.5，1.8，2，3，4，5 | Diameter（m) | 4 | 2.5 | 2,3 | 5 | 2,6,8,11 |
| LED Type | SMD1212 | SMD1212/1515 | SMD1515 | SMD1515 | SMD2121 | LED Type | SMD1515 | SMD1515 | SMD1921 | SMD2727 | SMD3535 |
| Pixel Density(dots/m2) | 284445 | 250000 | 160000 | 1111111 | 62500 | Pixel Density(dots/m2) | 43402 | 40000 | 27777 | 15625 | 10000 |
| Britghtness(cd/m2) | 1000 | 1000 | 1000 | 1000 | 1200 | Britghtness(cd/m2) | 5000 | 5000 | 5000 | 5000 | 7500 |
| Avg Power Consumption(w/m2) | 160 | 160 | 150 | 150 | 150 | Avg Power Consumption(w/m2) | 400 | 400 | 350 | 260 | 450 |
| Max Power Consumption（w/m2） | 480 | 480 | 450 | 450 | 450 | Max Power Consumption（w/m2） | 1000 | 1000 | 800 | 650 | 1100 |
| Refresh Rate（Hz） | 1920-3840 | Refresh Rate（Hz） | 1920-3840 | ||||||||
| Input Voltage | AC100-240v/50-60Hz | Input Voltage | AC100-240v/50-60Hz | ||||||||
| Life Span | 100000hours | Life Span | 100000hours | ||||||||
| Working Temperature | ·－20℃---60℃ | Working Temperature | ·－20℃---60℃ | ||||||||
| Working Humanity(RH) | 10%--90% | Working Humanity(RH) | 10%--90% | ||||||||
| Gray Scale | 12--16bit | Gray Scale | 12--16bit | ||||||||
