Discover our XRT Series 500x500mm Transparent Rental LED Screen with 50% see-through transparency, 4
>50% Transparency
Only 5kg Weight
4500 Nits Brightness
3840Hz Refresh Rate
Quick-Lock System
±15° Arc Splicing
IP40/IP65 Rating
Front & Rear Maintenance
1. Ultra-Lightweight Design
Only 5kg per 500×500mm cabinet (10kg for 500×1000mm), making it the lightest in its class. Reduces shipping costs and enables one-person handling.
2. High Transparency Rate
>50% transparency maintains natural light flow and visibility through the screen, ideal for stage performances and retail windows.
3. Exceptional Brightness
4500 nits outdoor / 900 nits indoor ensures content visibility in bright ambient lighting and direct sunlight.
4. Quick-Lock Installation
Tool-free setup with integrated quick-lock system and large handles allows single-person assembly in minutes.
5. Flexible Splicing Options
Mix 500×500mm and 500×1000mm panels freely. Supports flat, ±15° curved, and right-angle connections for creative designs.
6. Dual IP Ratings
IP40/IP21 for indoor controlled environments
IP65 for outdoor weather resistance
7. Camera-Friendly Performance
3840Hz refresh rate eliminates flicker on video cameras and broadcast equipment.
8. 10-Meter Safe Hanging
Engineered for rigging installations up to 10 meters height, meeting safety standards for large venues.
| Parameter | Indoor (XRT-P3.9) | Outdoor (XRTO3.9) |
|---|---|---|
| Pixel Pitch | 3.9mm | 3.9mm |
| LED Type | SMD2020 | SMD1921 |
| Transparency Rate | >50% | >50% |
| Brightness | 900 cd/㎡ | 4500 cd/㎡ |
| Cabinet Size | 500×500×83mm | 500×500×83mm |
| Cabinet Weight | 5kg | 5kg |
| Module Size | 500×125mm | 500×125mm |
| Resolution (500×500) | 128×128 pixels | 128×128 pixels |
| Refresh Rate | 3840Hz | 3840Hz |
| Grayscale | 14-bit | 14-bit |
| Viewing Angle | 140°×140° | 140°×140° |
| IP Rating | IP40/IP21 | IP65 |
| Power Consumption | 550W/175W (Max/Avg) | 750W/250W (Max/Avg) |
| Input Voltage | AC 100-240V | AC 100-240V |
| Curvature | ±15° arc | ±15° arc |
| Service Access | Front/Rear | Front/Rear |
Floor Stacking
Stack cabinets vertically using quick-lock connectors
Ground support frame for stable base
Suitable for stage backdrops and exhibition walls
Maximum height: 10 meters
Rigging & Hanging
Suspend from truss systems using rigging bars
Die-cast aluminum frame ensures structural integrity
Mandatory safety cables for overhead installations
Weight distribution: 5kg per 500×500mm panel
Wall Mounting
Fixed installation with wall brackets
Front and rear access for maintenance
Ideal for permanent retail displays
Mounting points on cabinet corners
Curved Configurations
±15° inner/outer arc connections
Right-angle 90° corner splicing
Custom shapes without additional hardware
Physical Specifications
Cabinet Dimensions: 500×500×83mm / 500×1000×83mm
Material: Die-casting aluminum
Thickness: 83mm
Weight: 5kg (500×500mm) / 10kg (500×1000mm)
Optical Performance
Pixel Pitch: 3.9mm - 7.8mm
Pixel Density: 32,768 pixels/m² (P3.9)
Contrast Ratio: 4000:1 (indoor) / 5000:1 (outdoor)
Color Temperature: 2000K-10000K (adjustable)
Electrical
Operating Voltage: AC 100-240V
Power Consumption: 550/175W per m² (indoor), 750/250W per m² (outdoor)
Certification: CB, EMC, LVD, ETL, FCC, TUV
Environmental
Operating Temperature: -20°C to 50°C
Storage Temperature: -40°C to 60°C
Humidity: 10%-90% RH (non-condensing)
IP Rating: IP40/IP21 (indoor), IP65 (outdoor)
