Flexible Curved LED Display 500×500mm for creative stages. ±20° (9-step) angle adjustment, indoor IP
3840HzHz
Foldable Design
≥800cd/m²
Easy to move
Smart Cloud Management
Front Maintenance
Die Cast Aluminum
60kg
±20° adjustable curvature: 9 adjustable angles from -20° to +20° for faster creative builds.
Convex & concave arc splicing supported for flexible stage designs.
Cylinder build capability: 8 panels form a cylinder with minimum 1.2m diameter.
Fast installation structure: left-right locks, handles, up-down locks, corner protectors.
High refresh rate: 3840–7680Hz for stable event visuals.
Maintenance: modules and power box support service (front/rear listed).
Rigging / hanging installation: up to 10m maximum height.
Stacking installation: up to 10m maximum height.
Curved splicing modes: convex arc, concave arc, and mixed splicing for more creative shapes.
Angle adjustment operation: press the handle and lock to the required angle position (9-step).
| Item | Indoor | Outdoor |
|---|---|---|
| Models | XRF1.9 / XRF2.6 / XRF2.9 / XRF3.9 | XRFO2.9 / XRFO3.9 |
| LED Type | SMD1515 (XRF1.9/2.6/2.9); SMD2020 (XRF3.9) | SMD1415 (XRFO2.9); SMD1921 (XRFO3.9) |
| Brightness (reference) | 900 cd/㎡ | 4000–5500 cd/㎡ |
